Introduction

Molybdenum telluride (MoTe₂) is a transition metal dichalcogenide that has gained attention due to its unique electrical, optical, and thermal properties. It typically exists in layered structures, which can be used to create thin films through various deposition techniques, including sputtering. Molybdenum telluride exhibits semiconductor behavior and is particularly noted for its potential applications in electronics and optoelectronics.

Applications

Electronics: Molybdenum telluride is used in the fabrication of semiconductor devices, including transistors and diodes. Its properties enable effective charge transport, making it suitable for advanced electronic applications.

Photodetectors: Due to its strong light-absorption capabilities and semiconductor nature, MoTe₂ can be used in photodetectors, which are crucial for various imaging and sensing technologies.

Thin Film Transistors (TFTs): Molybdenum telluride can be employed in the production of thin film transistors for displays, particularly in emerging technologies like flexible electronics and low-power applications.

Thermoelectric Devices: MoTe₂ has been investigated for use in thermoelectric materials, which can convert temperature gradients into electrical voltage. This application is valuable for energy harvesting and cooling technologies.

Energy Storage: Research into molybdenum telluride is ongoing for its potential use in batteries and supercapacitors, where its conductive properties can enhance charge storage and transfer.

Optoelectronic Devices: Molybdenum telluride’s optical properties make it suitable for use in optoelectronic devices, including light-emitting diodes (LEDs) and laser diodes.

Spintronics: Due to its layered structure and unique electronic properties, molybdenum telluride is being studied for applications in spintronics, where the spin of electrons is utilized for information processing.
